Malibu 85 Ww/red Satin Ss 4w Spr Mnt, 8-32vdc, Ip66 - Bcm34122ka85-34

  • Item No.: BCM34122KA85-34
  • Manufacturer: Imtra Marine Products
Regular price: $135.70
Sale price:$118.00
Qty.:
Contact us Now
  • Description

Malibu 85 Ww/red Satin Ss 4w Spr Mnt, 8-32vdc, Ip66 - Bcm34122ka85-34

BCM downlight fixtures are specifically designed for marine lighting applications. The downlights in this range are all offered in a 3000K warm white LED color and several sizes and finishes within each family. They are precision engineered to take advantage of the latest in LED technology. They feature lightweight construction, minimal power consumption, superior reliability and less radiated heat than traditional light sources. When installed properly, these products will provide years of dependable performance.

Specifications:

  • Certifications & Compliance: CE, EMC, RoHS, REACH
  • Output Color: Warm white/Red
  • Lifetime Hours: 50,000 hrs
  • Class: Class III
  • Dimmer Compatibility: DMS with a SPDT switch on the output for color selection
  • Cut-out Dimensions: 73mm (2.87in)
  • Trim Ring (Bezel) Dimensions: 85mm (3.35in) dia
  • Light Size: 3.35"
  • Manufacturers Part No: BCM34122KA85-34
  • Input Voltage: 10-30VDC
  • Finish: Satin Stainless Steel
  • Lens Material: Frosted glass
  • Recessed Depth: 1.22" (31mm)
  • Max Wattage: 4.0W
  • Ingress Protection: IP65+
  • Mounting Method: Wire springs
  • Light Technology: LED
  • Luminous Flux: 323 lms (White LED only)
  • Electrical Protections: Reverse Polarity, Transient & Spike Protection
  • Correlated Color Temperature (CCT): 3000K
  • Color Rendering Index (CRI): >80
  • Ingress Protection Rating (IP): IP65+
  • Approximate Ship Weight (lbs): 1
