  • Lumishore Thru-Hull Underwater Light - Ora Series THX203 UW Light
  • Lumishore Ora Series THX203, 58W Thru-Hull UW Light
  • Bronze Housing, Single Color Blue
  • The Lumishore Ora Series THX203 is an ultra slim thru-hull underwater light with shaft of just over 5/8" diameter, 3.75" long. It features the security of a thru-hull with a hole size and price point of a surface mount. Up to twice as bright and double the efficiency when tested against any competing light. Features a single color (white or blue) with an ultra wide 110° beam angle for the ultimate flood effect. Simple 2-wire installation with no external drivers, controlled by a standard on/off toggle switch.

Features:

  • Recommended for boats up to 80' in length
  • Flush fit suitable for transom or hull-side mounting
  • Ultra slim thru hull with shaft of just over 5/8" diameter
  • Ultra wide 110° beam angle
  • Just two wires and no external drivers needed

Specifications:

  • Trim Ring (Bezel) Finish/Material: Marine bronze
  • Housing Finish/Material: Bronze/Glass Lens
  • Lens Material: Toughened BK7 Borosilicate
  • Cut-Out Dimensions: 0.656 inch (16.5mm)
  • Recessed Depth: 3.78 inch (96mm)
  • Dimensions: See product sheet
  • Input Voltage: 10.5-31VDC
  • Power Consumption: 58W
  • Driver: Internal
  • Output Color: Blue
  • Luminous Flux: 12,600 lm (5,600 fixture lms)
  • Beam Angle: 110°
  • Lifetime Hours: 50,000 hrs
  • Mounting Method: Locking nuts (supplied)
  • Install Location: Tranzom, Bottom, Hull-Sides
  • Ingress Protection: IP68
  • Class: III
  • Electrical Protections: ATRB (automatic thermal rollback), surge, low voltage, soft start, reverse polarity, noise suppression
  • Certifitcations & Compliance: CE, ROHS, ABS
  • Manufacturer: Lumishore
  • Warranty: 2 Years
