Orion Dc-dc Converter 24-12v, 25a - Ori241225020

Orion Dc-dc Converter 24-12v, 25a - Ori241225020

High Power Orion DC-DC Converter Non-isolated

Features

• Remote on-off connector. The remote on-off eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by the engine run/stop switch.
• All models with adjustable output can also be used as a battery charger. For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.
• All models with adjustable output can be paralleled to increase output current. Up to five units can be connected in parallel.

Specifications:

• Certifications & Compliance: EN60950, EN61000-6-3, EN55014-1, EN61000-6-2, EN61000-6-1, EN55014-2, ECE R10-4
• Continuous Output Current: 25A
• DC Connection: Faston Tabs 6.3mm
• Galvanic Isolation: No
• Max Cable Cross Section: n/a
• Max Output Current: 35A
• Offload Current: <15mA
• Manufacturers Part No: ORI241225020
• Input Voltage: 18-35VDC
• Output voltage: 12V
• Operating Temperature: -20°C to +55°C
• Efficiency: 96%
• Approximate Ship Weight (lbs): 2
